Bubble washing machineWashing equipment
Bubble Washing Machine
A bubble washing machine with high-pressure sprayers for a clean rinse — air-bubble agitation, overflow chute for impurity discharge, water circulation system, 1,500 kg/h capacity.
Applications
- Leafy vegetable washing
- Fruit and berry cleaning
- Fresh-cut vegetable preprocessing
- Delicate produce that needs gentle washing
Features
- Air-bubble agitation + high-pressure sprayersAir bubbles gently dislodge dirt while high-pressure sprayers on top deliver a clean rinse.
- Overflow chute for impurity dischargeAn overflow chute beneath the machine collects and discharges impurities for easy maintenance.
- Water circulation systemWater is circulated for an environmentally friendly washing process.
- 1,500 kg/h capacityHandles commercial-scale washing with 304 stainless steel construction.
Technical Specifications
- Capacity
- 1,500 kg/h
- Washing method
- Air-bubble agitation + high-pressure sprayers
- Material
- 304 stainless steel
- Power
- 8.7 kW
- Dimensions (L×W×H)
- 5,500 × 1,780 × 1,810 mm
- Water system
- Circulation with overflow impurity discharge
- Conveyor
- Food-grade, detachable
- Application
- Leafy vegetables, fruits, berries
Working Process
Feeding
Produce is placed on the food-grade conveyor belt.
Bubble washing + rinse
Air-bubble agitation gently dislodges dirt while high-pressure sprayers deliver a clean rinse from above.
Overflow impurity discharge
The overflow chute beneath the machine collects and discharges impurities; water is circulated for eco-friendly operation.
Discharge
Clean produce exits the washing tank for drying or further processing.
Working Video
Project References
Projects built with this machine — country, capacity and configuration only.
FAQ
What produce suits bubble washing?
Leafy vegetables, berries, and delicate fruits that need gentle cleaning without damage.
How does the water circulation work?
An overflow chute beneath the machine collects and discharges impurities while water is circulated, making the process more environmentally friendly.
