Weighing printing and labeling machineWeighing printing and labeling machine

Packing equipment

Weighing, Printing and Labeling Machine

An integrated weighing, printing and labeling machine — dynamic weighing, real-time label printing and non-contact label application at up to 45 packs per minute.

Applications

  • Packed vegetable and fruit bags
  • Weight-price-barcode labeling
  • Traceable retail packs
  • Lines after pillow or net bag packing
Request a Machine Recommendation

Features

  • 45 packs/minuteReal-time weighing, printing and non-contact label application matched to your line speed.
  • ±3 g weighingDynamic weighing with automatic price calculation and barcode generation for traceability.
  • Pneumatic air-blow labelingSelf-developed applicator adapts to height differences and labels without touching the product — patent protected.
  • One computer controlPLC, printer and remote monitoring unified in a single industrial touch computer; ERP/MES/SAP integration available.

Technical Specifications

Labeling speed
Up to 45 packs/minute
Weighing accuracy
±3 g (3 kg)
Product size
Width ≤ 300 mm, length ≤ 700 mm
Power supply
220V / 50Hz, single phase
Rated power
Approx. 1,700 W
Air pressure
0.6–0.8 MPa, ≥ 100 L/min
Label content
Weight, price, barcode, batch — editable or system-fed
Machine dimensions
Approx. 2,100 × 900 × 1,600 mm

Working Process

  1. Dynamic weighing

    Each pack is weighed on the integrated scale as it passes the station.

  2. Real-time printing

    Label content — weight, price, barcode and batch — is generated and printed in real time.

  3. Non-contact application

    A pneumatic air-blow applicator applies the label without touching soft or irregular packs.

Related solution

See it inside a complete line

This machine is part of configured processing lines. Review the solution pages for the full process flow.

View the related processing line

Working Video

Project References

Projects built with this machine — country, capacity and configuration only.

Vegetable flow-pack weighing and labeling machine

Chili Flow-Pack Weighing and Labeling Line for a Canadian Packhouse

Chili · Canada · 1–1.5 t/h

Packing station / PackhouseVegetable weighing and labeling machine in a packing line

Chili Weighing and Labeling Machine for a Canadian Packhouse

Chili · Canada · 1–1.5 t/h

Packing station / PackhouseVegetable tray wrapping line prepared for shipment to Canada

Chili Film Wrapping and Labeling Line for a Canadian Packhouse

Chili · Canada · 1–1.5 t/h

Packing station / PackhouseLychee punnet packing line installed in an Australian orchard packhouse

Lychee Punnet Packing Line for an Australian Orchard

Lychee · Australia · 20–30 boxes/min

Farm / Orchard

View all project cases

FAQ

What label content can it print?

Weight, price, barcode and batch information — edited manually or fed automatically from ERP/MES/SAP systems.

Does the label touch the product?

No — a patented pneumatic air-blow applicator applies labels without contact, adapting to height differences.

What accuracy does the scale offer?

±3 g on a 3 kg weighing range.
