Lid-and-Base Fruit Box Forming Machine
Forms premium fruit boxes with a separate lid and base structure — gift boxes, retail display boxes and rigid-style fruit packaging at 2,000–3,500 boxes per hour.
Applications
- Premium fruit gift boxes
- Retail fruit boxes
- Lid-and-base fruit boxes
- Rigid-style fruit packaging
Features
- 2,000–3,500 boxes/hourHigh-speed forming for premium lid-and-base fruit packaging.
- 1.5–7 mm cardboardRigid-style boxes from 220–680 mm square and 100–250 mm high.
- Premium presentationSeparate lid and base structures for gift and retail fruit packaging.
- FST model namingPublic model FST-CF1000-LB.
Technical Specifications
- Public model
- FST-CF1000-LB
- Box structure
- Lid-and-base fruit box
- Speed
- 2,000–3,500 boxes/hour
- Cardboard thickness
- 1.5–7 mm
- Box size (L×W×H)
- 220–680 × 220–680 × 100–250 mm
- Total power
- 12 kW (approx. 5 kW in production), 380V / 50Hz
- Machine weight
- Approx. 1,600 kg
- Dimensions (L×W×H)
- 3,900 × 1,630 × 2,550 mm
Working Process
Base forming
The base box is formed from flat cardboard with glued corners.
Lid forming
The matching lid is formed in the same cycle for a precise fit.
Box output
Lid-and-base pairs are discharged for premium fruit packing.
Working Video
FAQ
Which boxes does it form?
Premium lid-and-base fruit boxes for gift and retail packaging where presentation matters.
What speed does it reach?
2,000–3,500 boxes per hour with 1.5–7 mm cardboard.
