Garlic Net Bag Packaging Machine
Fully automatic garlic net bag packaging line with photoelectric counting, figure-8 wire tying and servo labeling — one operator, 15–25 bags per minute.
Applications
- Garlic bulb net bag packing
- Count-based retail and food-service packs
- Supermarket-ready garlic presentation
Features
- One-operator automationAutomatic feeding, counting, packing, tying and labeling — the whole line needs one person.
- Accurate counting, adjustable quantityPhotoelectric counting with a dual-channel mechanism, adjustable from 3 to 8 cloves per bag.
- Vertical net bag packingGarlic cloves are arranged vertically in sleeve-style mesh bags, ideal for supermarket display.
- Figure-8 wire tyingFirm, aesthetic tying with no exposed sharp ends.
- Triple auto alarm & stopAutomatic alarm and stop for no mesh bag, no tying wire, or no label.
- Spare drum auto-switchTwo mesh bag drums — when one empties, the turntable rotates to the spare without stopping production.
Technical Specifications
- Packaging quantity
- 3–8 pieces per net bag
- Packaging speed
- 15–25 bags/min
- Max bag length
- 500 mm
- Bag type
- Sleeve-style mesh bag
- Tying method
- Figure-8 wire tying
- Label feeding
- Servo-driven
- Frame material
- Stainless steel 304
- Power supply
- 220V/50Hz, 5 kW
- Air consumption
- 0.5 m³/h
- Counting machine dimensions
- 4500 × 700 × 700 mm
- Net bag machine dimensions
- 1900 × 1700 × 1400 mm
- Conveyor dimensions
- 1900 × 1200 × 700 mm
- Total weight
- 800 kg
Working Process
Manual feeding
Workers pour garlic bulbs into the hopper.
Automatic counting
Photoelectric sensors count cloves; when the target quantity is reached, packaging triggers.
Vertical packing
Garlic falls vertically into the mesh bag by its own weight.
Tying and labeling
Wire is fed and tied in a figure-8; the servo label feeder applies the label automatically.
Conveyor output
Finished bags are conveyed out, ready for casing.
Working Video
FAQ
How many operators are needed?
Only one. The machine automatically feeds, counts, packs, ties and labels.
Can the packaging quantity be adjusted?
Yes, from 3 to 8 cloves per bag. Other quantities are available upon request.
What happens if the mesh bag runs out?
The machine alarms and stops; the spare drum rotates to continue production, so the empty drum can be replaced without stopping the line.
Is the label applied automatically?
Yes — the servo-driven label feeder applies each label precisely, fully enclosed inside the buckle.
